PV cells production

Our production facility is located in Kazakhstan with annual capacity of 200 MW. We produce photovoltaic solar cells in formats: M2+, M6, M10, G12.
Q1 2025
Start of production
200 MW/year
Production capacity
M2+, M6, M10, G12
Cell formats
up to 25%
PV cell efficiency

Standard product line

1

Various formats of HJT cells

production starts in January 2025

  • FORMAT G12 / M10 / M6 0BB

    Efficiency: up to 25%
    Interconnection: multiwire (solderable)
    Datasheet

  • FORMAT G12 20BB

    Efficiency: up to 25%
    Interconnection: multiwire (solderable)
    Datasheet

  • FORMAT M10 16BB

    Efficiency: up to 25%
    Interconnection: multiwire (solderable)
    Datasheet

  • FORMAT M6 12BB

    Efficiency: up to 25%
    Interconnection: multiwire (solderable)
    Datasheet

  • FORMAT M6 9BB

    Efficiency: up to 25%
    Interconnection: multiwire (solderable)
    Datasheet

  • FORMAT M2+ 0BB

    Efficiency: up to 24.5%
    Interconnection: foil-wire technology
    Datasheet

Customized solutions

2

Сustomized format
and thickness

  • CUSTOMIZED CONTACT GRID

    PV cell customized contact grid Solar cell customized contact grid
    Customization of MBB, SMBB, 0BB contact grid design according to specific customer requirements

  • CUSTOMIZED THICKNESS

    PV cell customized thickness Solar cell customized thickness
    Customization of cell thickness to match customer requirements on weight and bendability

production starts in 2025

PV cell-strings

Already assembled busbarless cell-string using foil-wire technology and ready for further lamination process.

Perfect aesthetics and uniform appearance due to 18 wires and bus bars absence. Enchanced microcracking resistance provided by multiple wires.
Characteristics:
  • Cells efficiency: up to 25%
  • Cell format: M2+ (157.35x157.35 mm)
  • Bifaciality: 90%
  • Temperature coefficient: -0.26 %/°С
Customizable string parameters:
  • Length of 1-18 cells
  • 1.5-3 mm cell-to-cell distance
  • 15-24 mm free length of foil-wire electrode at the string ends
  • Optional side of cross-ribbon applying

Why HJT cells

We offer high-quality heterojunction cells that are efficient, durable, and cost-effective.

  • High efficiency

    The most efficient and the most reliable technology in the industry.

  • Temperature coefficient

    Less affected by changes in temperature, making it great for use in high-temperature locations, with trackers, under direct sunlight at noon and in case of complicated heat sink.

  • Bifaciality factor

    High bifaciality making them a great choice for utility-scale applications that can take advantage of the albedo resource up to 4,6% power generation.

  • Minimum degradation

    Lower degradation results in 5% more power than other technologies after 30 year.

  • Technology of future

    More promising in the future, it’s easier to combine it with perovskite.

  • Cost-effective

    Great potential for price decrease.
